Gibitre Instruments’ certified butyl rubber (isobutylene–isoprene) test specimens are a ready-to-use solution for verifying Mooney viscosity on your measuring instruments. Obtained without further processing from an IRM (Industry Reference Material) block prepared by the ASTM D11.20 group in accordance with ASTM D 4678, they provide a reliable reference for repeatable tests on elastomeric materials.
The vacuum-sealed package includes a lower specimen with standard volume and a central hole, an upper specimen with standard volume, two polyester sheets, and the acceptance limits for performing the 1+4 and 1+8 minute tests at 100°C and 125°C. The code to download the IRM block’s Test Certificate is also included.
Why choose these test specimens:
- They support proper test setup thanks to the provided acceptance limits.
- They offer documented traceability through IRM certification.
- They ensure compliance with the procedures defined by ASTM D 4678.
Whether in the laboratory or in production, they serve as a reliable and immediate reference to ensure the correct calibration of your Mooney viscometers.
Pair of certified butyl rubber specimens (Isobutylene - Isoprene) for the verification of Mooney Viscosity.
The specimens are obtained, without rework, from a bale coded as IRM (Industry Reference Material) prepared by the working group ASTM D11.20 (task Group subcommittee on Compounding Materials and Procedures) in accordance with ASTM D 4678.
The vacuum pack includes:
- N ° 1 lower specimen with standard volume and central hole
- N ° 1 Upper specimen with standard volume
- N ° 2 polyester sheets for the test
- Acceptability limits for carrying out the viscosity test 1 + 4 min @ 100 ° C
- Acceptability limits for carrying out the viscosity test 1 + 8 min @ 100 ° C
- Acceptability limits for carrying out the viscosity test 1 + 4 min @ 125 ° C
- Acceptability limits for carrying out the viscosity test 1 + 8 min @ 125 ° C
- Code for Downloading the IRM Bale Test Certificate prepared by Taks Group ASTM D11.20
Verification of viscosity using certified specimens does not replace the calibration of the instrument which must be carried out according to the procedures described in the ISO 289-1 standard and equivalent.
Verification by specimens is a valid method to verify that the instrument provides correct results in the period between two successive calibrations or after Ordinary maintenance and cleaning activities.
